Availability of Teledyne LeCroy PCIe 5.0 Mini Cool Edge IO Interposer

Teledyne LeCroy announced a PCIe 5.0 Mini Cool Edge IO (MCIO) interposer that works in combination with its Summit family of PCIe 5.0 protocol analyzers.

This interposer enables engineers to test products that incorporate card edge connectors or cabled connector assemblies that utilize the MCIO mechanical connector with PCIe 5.0, NVMe or Compute Express Link (CXL) technologies. It joins the list of CrossSync PHY enabled interposers, allowing users to debug enhanced power management and link training equalization through correlated and time aligned physical and protocol layer views. No other solution gives this type of insight into link behavior.

The Mini Cool Edge IO connector is a flexible, and cost-effective connector and cable assembly that helps equipment designers offer flexibility, reduce overall space requirements, and extend the reach for high data rate signals. MCIO connectors and cabled connector assemblies are used extensively in server/storage devices, HPC, switches/routers, and other data center equipment. Now, design and test engineers can test, identify issues, and optimize MCIO connector/cable designs using the firm’s PCIe 5.0 MCIO interposer in combination with one of the Summit PCIe 5.0 protocol analyzers, at data rates of 2.5, 5.0, 8.0, 16.0 and 32GT/s in standard or multiport configurations. The Interposer provides probing capability of up to 16 lanes of PCIe 5.0 traffic on multiple x8 (74 pin) MCIO connections, based on the SFF- TA-1016 spec.

About CrossSync PHY
A CrossSync PHY-capable interposer probes a PCIe link for simultaneous capture of both oscilloscope and protocol analyzer traces, providing insight into protocol-directed electrical behaviors to design and validation engineers. The CrossSync PHY software option for the company’s LabMaster and WaveMaster oscilloscopes enables the oscilloscope’s MAUI user interface to be viewed directly alongside the industry-standard firm’s CATC protocol trace. The combination of the interposer and the software option permits the oscilloscope and protocol analyzer traces to be viewed, navigated, and analyzed in a time-correlated way unique to the company.

Availability

• The PCIe 5.0 MCIO Cable Interposer, which can be optionally upgraded with CrossSync PHY support, has been added to the company’s PCIe test solutions product line with the product codes of G5 MCIO Cable Interposer (74 Pin Connectors) PE249UIA-X.

• The CrossSync PHY software option is supported with LabMaster or WaveMaster oscilloscopes.

• All products are available for order.
