CEA-Leti Research Team Proposes New Approach for Next-Gen Memories With RRAM Energy-Storage

In a breakthrough that is expected to advance in-memory energy-storage in Resistive-RAM (RRAM) devices, CEA-Leti has proposed a ‘newfangled approach’ that allows these devices to operate as energy-storage elements as well as memory, depending on the applied bias.

Radically different’ concept enables ‘Dual-behavior’ devices – That can store data and energy

In-memory energy is a supplemental feature to in-memory computing, which is a key focus in CEA-Leti’s roadmap. It can reduce energy use dramatically because RRAM-based batteries are highly scalable and dynamically allocable, and they can be placed next to memory blocks, which are near the processor. Locating the energy supply close to the processor is especially helpful when the processor requires peak power, which typically comes from an external source.

This reduces power use over transmission lines, while improving power-delivery network (PDN) efficiency. In addition to showing increased energy-and-power density, the hybrid, dual-behavior device proposed by CEA-Leti also is compatible with CMOS fabrication processes.

“Our work attempts to tackle the modern demand of energy-efficient computation with an innovative approach, radically different from state-of-the-art solutions” said Gaël Pillonet, senior expert. “This capability would be highly beneficial, allowing localized and high-bandwidth energy supply to the nearby processing unit and the memory. Our study is the first report on the feasibility of a practical implementation of the nanobattery effect in RRAMs, with quantification of the energy-and- power density capabilities, and a comparison with the best current solutions.”

RRAM is considered a leading candidate in next-generation memory because of its promising performance in scalability, in cost and CMOS-process compatibility.

The research results were reported in a recent paper in Advanced Electronic Materials, In Memory Energy Application for Resistive Random-Access Memory.

The high energy-and-power densities are due to the fact that the RRAM devices in the study rely on faradaic processes to store information inside an active volume, enabling the extracted values (power-and-energy densities) to far exceed that of electrostatic capacitors, and which are comparable to micro-supercapacitors. In addition, the technology is far more scalable: a cell size exhibits an area as low as 10-7mm², without loss of energy-storage capability, whereas state-of-the-art supercapacitors are around 10-3 mm². That means the proposed devices are 104x more scalable than the smallest-footprint micro-supercapicitors.

The high energy scalability is allowed by the small physical scale of RRAM devices, which involve a sub-nanometer- thick partial filament to store the energy: typical device areas are in the range of [0.1-1]10-7 mm² and are expected to scale down in the near future.

Projected applications for these energy-use-cutting, dual-behavior devices include energy-to-memory (NAND and NOR Flash), energy-to-logic (IoT processors) and neuromorphic uses (synaptic technology).

“Our study points out that energy storage in RRAM exhibits ‘local’ traits, similar to the memory effect, and thus does not increase with the device area, as opposed to standard solid-state batteries and micro-supercapacitors,” said Paola Trotti, Ph.D. researcher and an author of the paper. “It follows that decreasing the size of samples, and connecting them in parallel, should allow for higher energy density. In addition, CMOS-compatibility supports downscaling, which increases with more advanced technology nodes.”

The research is a first step. Future work will aim to quantify the output voltage, columbic efficiency, experimental-energy and power-density capability in discharge mode, as well as proper peripheral circuits to deal with the memory/energy storage dual operation. More immediately, new design solutions in which the memory and energy performances are optimized will be explored to bring the technology to the application level.

Article: In Memory Energy Application for Resistive Random Access Memory

Advanced Electronic Materials has published an article written by Paola Trotti, Sami Oukassi, Gabriel Molas, Mathieu Bernard, François Aussenac, and Gaël Pillonnet, CEA, LETI, Univ. Grenoble Alpes, Grenoble, 38000 France.

Abstract: “This work explores the innovative concept of a hybrid dual-behavior device, based on emerging nonvolatile memory technology, for both data retention and energy storage. RRAM (resistive random access memory) is considered a major candidate as next-generation memory, thanks to its promising performances in terms of scalability and CMOS process compatibility. Its working mechanisms, based on faradaic processes, motivate the study on the feasibility of operating RRAM also as energy storage element. To evaluate the energy capability, various electrochemical characterizations on state-of-the-art RRAM are presented. The highly resistive electrolyte, extremely small physical scale (nm), and current range (pA), put in quite a critical framework, far from conventional solid-state batteries. Cyclic voltammetry tests reveal that although no oxidation peak appears during the redox cycle, the cells behave as standard electrochemical storage elements when investigating the impact of the scan rate, maximum positive voltage, and area on the reduction peak. Concentration and diffusion coefficients are derived, in the order of 10⁻¹² cm² s⁻¹ and few mmol cm⁻³, respectively, while energy storage capability amounts to 3.5 pJ µm⁻². Finally, design concepts are proposed, where RRAM ‘in-memory energy’ technology would be a newfangled approach to meet the needs of various emerging and standard applications.“
