Teledyne LeCroy Supporting PCIe 4.0 Reliability, Accessibility and Serviceability Testing

Teledyne LeCroy Inc. announced its PCIe 4.0 RAS (Reliability, Accessibility and Serviceability) test solution for the Summit M5x PCIe protocol analyzer/jimmer, a platform to support PCIe RAS error injection.

PCIe RAS testing using Summit M5x Analyzer/Jammer
Click to enlarge

With its PCIe 4.0 compliant jamming capability, the Summit M5x delivers test functionality sought after by engineers trying to ensure improved system robustness. Moreover, it injects RAS errors between a standard Root Complex and Endpoint in adherence to design specs to identify potential error handling problems.

PCIe RAS testing using summit M5x analyzer/jammer
The Summit M5x PCIe protocol analyzer/jammer provides multi-protocol support for PCIe, NVMe and Gen-Z in a single box at transmission speeds of up to 32GT/s, allowing for a new class of analysis and test for devices, servers, add-in cards and switches. It is also a protocol analyzer to introduce jamming capabilities for NVMe and NVMe-MI protocols. In addition to its ability to jam transmissions between the root complex and endpoint while remaining within normal PCIe operating specs, the Summit M5x can capture, decode, modify, and describe virtualized systems in a multitude of configurations. The RAS testing functionality supports PCIe links up to 16 lanes at 16GT/s, and includes the LinkExpert RAS tests to automate the testing and validation of system level error handling and reporting mechanisms.

“RAS requirements were driven by the server community who need servers to be reliable; they need them to be accessible through the network; and they need to be able to troubleshoot issues and repair or correct problems quickly. We have responded to these industry demands by enabling testing to ensure that these requirements are being fully met,” said Joe Mendolia, VP, marketing, protocol solutions group. “With high-speed, state-of-the-art capture, recording, and jamming, the Summit M5x positions Teledyne to deliver unique value to our customers as the industry moves forward with higher-performing systems.“

The Summit M5x PCIe RAS testing solution is available for order.
